Study on the Component and Distribution Characteristics of Needle-like Inclusions in Rose Quartz

Zhe HU; Ying GUO

doi:10.15898/j.cnki.11-2131/td.201709150152

2018 Vol. 37, No. 3

Article Contents

Article navigation > Rock and Mineral Analysis > 2018 > 37(3): 306-312

Next Article Previous Article

Zhe HU, Ying GUO. Study on the Component and Distribution Characteristics of Needle-like Inclusions in Rose Quartz[J]. Rock and Mineral Analysis, 2018, 37(3): 306-312. doi: 10.15898/j.cnki.11-2131/td.201709150152

Citation:

Zhe HU, Ying GUO. Study on the Component and Distribution Characteristics of Needle-like Inclusions in Rose Quartz[J]. Rock and Mineral Analysis, 2018, 37(3): 306-312. doi: 10.15898/j.cnki.11-2131/td.201709150152

Study on the Component and Distribution Characteristics of Needle-like Inclusions in Rose Quartz

Zhe HU,
Ying GUO^,

School of Gemmology, China University of Geosciences(Beijing), Beijing 100083, China

More Information

Corresponding author: Ying GUO, guoying@cugb.edu.cn

Received Date: 15 September 2017

Revised Date: 24 March 2018

Accepted Date: 07 May 2018

Abstract

Abstract

BACKGROUND The needle-like inclusions in rose quartz are considered to be rutile or dumortierite, and their orientation is related to the c-axis. However, there is no consensus on this statement. OBJECTIVES To find out the distribution characteristics and component of needle-like inclusions in rose quartz using multiple methods. METHODS Four starlight powder crystals containing acicular inclusions were selected, observed and tested using gemological Microscopes, Laser Raman Spectroscopy, and Ultraviolet-visible Absorption Spectroscopy. RESULTS The Raman experiments show that the characteristic vibration peaks 949 cm^-1 and 999 cm^-1 of needles match those of dumortierite and the needle-like inclusions are dumortierite or minerals similar to dumortierite. Magnification examination reveals that the inclusions are approximately 0.5 μm in diameter, with a length of up to millimeters, a near-directional distribution, and a convergent shape as a whole. They can be roughly divided into three groups at certain positions. The needle-like inclusions in the same group are distributed approximately parallel. The three blue-ray lines of six-pointed starlights intersected three-dimensionally, and no obvious three-dimensional symmetry was observed. It was not directly related to the crystallization habit of crystals. CONCLUSIONS It is believed that blue-ray stones form inclusions first and are captured during the growth of crystals. The UV-visible Spectroscopic Spectrum only absorbs the pink dumortierite, indicating that a large number of pink dumortierite inclusions contribute to the pinkness of the pink crystal.
- rose quartz /
- needles /
- dumortierit /
- Laser Raman Spectroscopy /
- Ultraviolet-visible Absorption Spectroscopy

FullText(HTML)

References

[1]	张蓓莉.系统宝石学[M].北京:地质出版社, 2006:260-269. Google Scholar Zhang B L.Systematic Gemmology[M].Beijing:Geological Publishing House, 2006:260-269. Google Scholar
[2]	White J S.Mineral mysteries:Star rose quartz[J].Rocks & Minerals, 2015, 90(3):282-284. Google Scholar
[3]	Hori H.Nomenclature of quartz color variations-Pink and rose[J].Mineralogical Record, 2001, 32:42. Google Scholar
[4]	Guo Y, Wang H, Du H.The foundation of a color-chip evaluation system of jadeite-jade green with color difference control of medical device[J].Multimedia Tools & Applications, 2016, 75(22):1-12. Google Scholar
[5]	Guo Y, Wang H, Li X, et al.Metamerism appreciation of jadeite-jade green under the standard light sources D65, A and CWF[J].Acta Geologica Sinica, 2016, 90(6):2097-2103. doi: 10.1111/acgs.2016.90.issue-6 CrossRef Google Scholar
[6]	Guo Y.Quality grading system of jadite-jade green based on three colorimetric parameters under CIE standard light sources D65, CWF and A[J].Bulgarian Chemical Communications, 2017, 49(4):961-968. Google Scholar
[7]	Guo Y, Zong X, Qi M.Feasibility study on quality evaluation of jadeite-jade color green based on gem dialogue color chip[J].Multimedia Tools & Applications, 2018:1-16. Google Scholar
[8]	黄凤鸣, 刘慧芳, 李娅莉, 等.合成扩散星光刚玉的物理性质及成因探讨[J].地球科学——中国地质大学学报, 2003, 28(3):255-260. Google Scholar Huang F M, Liu H F, Li Y L, et al.Physical properties and origins of synthetic and diffused star corundum[J].Earth Science-Journal of China University of Geosciences, 2003, 28(3):255-260. Google Scholar
[9]	田亮光, 黄文慧, 刘化峰, 等.星光尖晶石的研究[J].宝石和宝石学杂志, 2004, 6(2):1-3. Google Scholar Tian L G, Huang W H, Liu H F, et al.Study on star spinel[J].Journal of Gems & Gemmology, 2004, 6(2):1-3. Google Scholar
[10]	林维峰, 邹耀辛, 迟广成.天然水晶片中双晶纹的成因及其鉴定意义[J].岩矿测试, 2002, 21(1):66-67. Google Scholar Lin W F, Zou Y X, Chi G C.Origin of twin stripe in natural rock crystal blade and its identification significance[J].Rock and Mineral Analysis, 2002, 21(1):66-67. Google Scholar
[11]	裴育. 水晶的宝石学特性、雕刻工艺及评价[D]. 北京: 中国地质大学(北京), 2015.http://cdmd.cnki.com.cn/Article/CDMD-11415-1015387254.htm Google Scholar Pei Y. The Gemological Characteristics of Rock Crystal, Carving Techniques and Evaluation of Process[D]. Beijing: China University of Geosciences (Beijing), 2015. Google Scholar
[12]	Kibar R, Garcia-Guinea J, Cetin A, et al.Luminescent, optical and color properties of natural rose quartz[J].Radiation Measurements, 2007, 42(10):1610-1617. doi: 10.1016/j.radmeas.2007.08.007 CrossRef Google Scholar
[13]	吕林素, 刘珺, 李宏博.红、蓝宝石的加工技法[J].宝石和宝石学杂志, 2006, 8(1):22-25. Google Scholar Lü L S, Liu J, Li H B.Study on fashion skills of ruby and sapphire[J].Journal of Gems & Gemmology, 2006, 8(1):22-25. Google Scholar
[14]	Mcmillan P F, Wolf G H, Lambert P.A Raman spectro-scopic study of shocked single crystalline quartz[J].Physics & Chemistry of Minerals, 1992, 19(2):71-79. Google Scholar
[15]	Champagnon B, Panczer G, Chemarin C, et al.Raman study of quartz amorphization by shock pressure[J].Journal of Non-Crystalline Solids, 1996, 196:221-226. doi: 10.1016/0022-3093(95)00590-0 CrossRef Google Scholar
[16]	Ostroumov M, Faulques E, Lounejeva E.Raman spectros-copy of natural silica in Chicxulub impactite, Mexico[J].Comptes Rendus Geoscience, 2002, 334(1):21-26. doi: 10.1016/S1631-0713(02)01700-5 CrossRef Google Scholar
[17]	李颖, 段玉然, 李维华.采用拉曼光谱技术研究纳米锐钛矿到金红石的相转变[J].光谱学与光谱分析, 2002, 22(5):783-786. Google Scholar Li Y, Duan Y R, Li W H.Study on nanophase anatase-rutile transition with Raman spectrum[J].Spectroscopy and Spectral Analysis, 2002, 22(5):783-786. Google Scholar
[18]	赵一鸣, 李大新, 韩景仪, 等.内蒙古羊蹄子山-磨石山钛矿床锐钛矿、金红石和钛铁矿的矿物学特征[J].矿床地质, 2008, 27(4):466-473. Google Scholar Zhao Y M, Li D X, Han J Y, et al.Mineralogical characteristics of anatase, rutile and ilmenite in Yangtizishan-Moshishan titanium ore deposit, Inner Mongolia[J].Mineral Deposits, 2008, 27(4):466-473. Google Scholar
[19]	Goreva J S, Ma C, Rossman G R.Fibrous nanoinclusions in massive rose quartz:The origin of rose coloration[J].American Mineralogist, 2001, 86(4):466-472. doi: 10.2138/am-2001-0410 CrossRef Google Scholar
[20]	谢先德, 查福标.硼酸盐矿物的振动光谱研究.Ⅰ:拉曼光谱特征[J].矿物学报, 1993, 13(2):130-136. Google Scholar Xie X D, Zha F B.Vibrational spectral study of borates.Ⅰ:Raman spectroscopy[J].Acta Mineralogica Sinica, 1993, 13(2):130-136. Google Scholar
[21]	彭卓伦.蓝线石的矿物学特征[J].矿物岩石地球化学通报, 1998, 17(3):72. Google Scholar Peng Z L.Mineralogy characteristics of dumortierite[J].Bulletin of Mineralogy, Petrology and Geochemistry, 1998, 17(3):72. Google Scholar
[22]	Platonov A N, Langer K, Chopin C, et al.Fe²⁺ -Ti⁴⁺ charge-transfer in dumortierite[J].European Journal of Mineralogy, 2000, 12(3):521-528. doi: 10.1127/ejm/12/3/0521 CrossRef Google Scholar
[23]	Alexander V D, Griffen D T, Martin T J.Crystal chemistry of some Fe-and Ti-poor dumortierites[J].American Mineralogist, 1986, 71(5-6):786-794. Google Scholar
[24]	Borghi A, Cossio R, Fiora L, et al.Chemical determina-tion of coloured zoned minerals in 'natural stones' by EDS/WDS electron microprobe:An example from dumortierite quartzites[J].X-Ray Spectrometry, 2004, 33(1):21-27. doi: 10.1002/(ISSN)1097-4539 CrossRef Google Scholar
[25]	Renfro N, Sun Z, Koivula J.Dumortierite in rock crystal quartz[J].Gems & Gemology, 2015, 51(1):100-102. Google Scholar
[26]	Meshram R R, Ingle K B.Mineralogy and origin of dumortierite from Girola area, Bhandara district, Eastern Maharashtra[J].Journal of the Geological Society of India, 2012, 79(2):181-188. doi: 10.1007/s12594-012-0020-4 CrossRef Google Scholar
[27]	Applin K R, Hicks B D.Fibers of dumortierite in quartz[J].American Mineralogist, 1987, 72:170-172. Google Scholar
