Qiao-juan YAN, Xiao-yan WEI, Mei-fang YE, Hui-bo ZHAO, Ning-chao ZHOU. Determination of Composition of Pyrite in the Baishantang Copper Deposit by Laser Ablation-Inductively Coupled Plasma-Mass Spectrometry and Electron Microprobe[J]. Rock and Mineral Analysis, 2016, 35(6): 658-666. doi: 10.15898/j.cnki.11-2131/td.2016.06.012
Citation: Qiao-juan YAN, Xiao-yan WEI, Mei-fang YE, Hui-bo ZHAO, Ning-chao ZHOU. Determination of Composition of Pyrite in the Baishantang Copper Deposit by Laser Ablation-Inductively Coupled Plasma-Mass Spectrometry and Electron Microprobe[J]. Rock and Mineral Analysis, 2016, 35(6): 658-666. doi: 10.15898/j.cnki.11-2131/td.2016.06.012
shu

Determination of Composition of Pyrite in the Baishantang Copper Deposit by Laser Ablation-Inductively Coupled Plasma-Mass Spectrometry and Electron Microprobe

  • Xi'an Geological Survey Center, China Geological Survey, Xi'an 710054, China

Received Date:  14 March 2016
Revised Date:  10 October 2016
Accepted Date:  18 November 2016
    Abstract
  • Determination of trace elements in analyzed mineral phase by Laser Ablation-Inductively Coupled Plasma-Mass Spectrometry (LA-ICP-MS) is a new in situ technique for mineral phase analyses. As an important mineral in porphyry copper deposits, the major and trace elements of pyrite can provide important information for the ore-forming process. A method for determination of the trace elements in pyrite by LA-ICP-MS and major elements by Electron Microprobe was developed and has been applied to the Baishantang porphyry copper ore district. For the LA-ICP-MS experiment, the laser beam is 60 μm, the carrier gas is helium, the repetition frequency is 5 Hz, the laser energy is 6 J/cm2, and the analysis time of single point is 60 s. Iron was used as an internal standard and MASS-1 was used to calibrate the data. Analysis precision of most elements is better than 10%. For the similar optical properties of pyrite and arsenopyrite, the differences of physical properties can be used to distinguish them. Pyrite in the Baishantang porphyry copper deposit is depleted in sulfur but rich in iron, indicating a hydrothermal origin. The trace element composition of pyrite indicates that pyrite was formed at a medium depth and belongs to the medium-low temperature hydrothermal type related to volcanism. This conclusion has provided important evidence for the ore genesis and the source of ore-forming fluids of the Baishantang porphyry copper deposit, which can also guide the next-step exploration.
    • FullText(HTML)
  • 加载中
    • References
  • [1] Arehart G B,Eldridge C S,Chryssoulis S L,et al.Ion Microprobe Determination of Sulfur Isotope Variations in Iron Sulfides from the Post/Betze Sediment-hosted Disseminated Gold Deposit,Nevada,USA[J]. Geochimica et Cosmochimica Acta,1993,57:1505-1519. doi: 10.1016/0016-7037(93)90010-T

    CrossRef Google Scholar

    [2] 严育通,李胜荣,贾宝剑,等.中国不同成因类型金矿床的黄铁矿成分标型特征及统计分析[J].地学前缘,2012,19(4):214-226.

    Google Scholar

    Yan Y T,Li S R,Jia B J,et al.Composition Typomorphic Characteristics and Statistic Analysis of Gold Deposits of Different Genetic Types[J].Earth Science Frontiers,2012,19(4):214-226.

    Google Scholar

    [3] 寇大明,黄菲,姚玉增,等.黄铁矿晶体形貌学研究进展[J].矿物学报,2009,29(3):333-337.

    Google Scholar

    Kou D M,Huang F,Yao Y Z,et al.Progress in the Pyrite Crystal Morphology[J].Acta Mineralogica Sinica,2009,29(3):333-337.

    Google Scholar

    [4] 黄菲,寇大明,宋丹,等.山西耿庄黄铁矿晶须形貌的显微观测及其标型意义[J].地质学报,2011,85(9):1486-1492.

    Google Scholar

    Huang F,Kou D M,Song D,et al.Microscopic Obvervation of the Pyrite Whisker Patterns in Gengzhuang,Shanxi Province,and Its Typomorphic Significance[J].Acta Geologica Sinica,2011,85(9):1486-1492.

    Google Scholar

    [5] 宫丽,马光.黄铁矿的成分标型特征及其在金属矿床中的指示意义[J].地质找矿论丛,2011,26(2):162-166.

    Google Scholar

    Gong L,Ma G.The Characteristic Typomorphic Composition of Pyrite and Its Indicative Meaning to Metal Deposits[J].Contributions to Geology and Mineral Resources Research,2011,26(2):162-166.

    Google Scholar

    [6] 严育通,李胜荣,张娜,等.不同成因类型金矿床成矿期黄铁矿成分成因标型特征[J].黄金,2012,33(3):11-16.

    Google Scholar

    Yan Y T,Li S R,Zhang N,et al.Composition Typomorphic Characteristics and Statistics Analysis of Metallogenic Pyrite in Gold Deposits of Different Genetic Types[J].Gold,2012,33(3):11-16.

    Google Scholar

    [7] 谢巧勤,陈天虎,范子良,等.铜陵新桥硫铁矿床中胶状黄铁矿微尺度观察及其成因探讨[J].中国科学(地球科学),2014,44(12):2665-2674.

    Google Scholar

    Xie Q Q,Chen T H,Fan Z L,et al.Morphological Characteristics and Genesis of Colloform Pyrite in Xinqiao Fe-S Deposit,Tongling,Anhui Province[J].Scientia Sinica Terrae,2014,44(12):2665-2674.

    Google Scholar

    [8] 周涛发,张乐骏,袁峰,等.安徽铜陵新桥Cu-Au-S矿床黄铁矿微量元素LA-ICP-MS原位测定及其对矿床成因的制约[J]. 地学前缘,2010,17(2):306-318.

    Google Scholar

    Zhou T F,Zhang L J,Yuan F,et al.LA-ICP-MS in situ Trace Elements Analysis of Pyrite from the Xinqiao Cu-Au-S Deposit in Tongling,Anhui,and Its Constraints on the Ore Genesis[J].Earth Science Frontiers,2010,17(2):306-318.

    Google Scholar

    [9] 袁继海,詹秀春,樊兴涛,等.硫化物矿物中痕量元素的激光剥蚀-电感耦合等离子体质谱微区分析进展[J].岩矿测试,2011,30(2):121-130.

    Google Scholar

    Yuan J H,Zhan X C,Fan X T,et al.Development of Microanalysis of Trace Elements in Sulfide Minerals by Laser Ablation-Inductively Coupled Plasma-Mass Spectrometry[J].Rock and Mineral Analysis,2011,30(2):121-130.

    Google Scholar

    [10] 罗彦,刘勇胜,胡圣虹,等.激光剥蚀电感耦合等离子体质谱测定岩石样品中稀土元素[J].地球科学——中国地质大学学报,2001,26(5):508-512.

    Google Scholar

    Luo Y,Liu Y S,Hu S H,et al.Rare Earth Elements Analysis of Geological Samples by LA-ICP-MS[J].Earth Science-Journal of China University of Geosciences,2001,26(5):508-512.

    Google Scholar

    [11] 肖志斌,柳小明,李正辉,等.激光剥蚀-电感耦合等离子体质谱准确测定锆石中钛的含量[J].岩矿测试,2012,31(2):229-233.

    Google Scholar

    Xiao Z B,Liu X M,Li Z H,et al.Accurate Determination of Ti in Zircon by Laser Ablation-Inductively Coupled Plasma-Mass Spectrometry[J].Rock and Mineral Analysis,2012,31(2):229-233.

    Google Scholar

    [12] 陕亮,许荣科,郑有业,等.北山地区白山堂铜多金属矿区岩浆岩锆石LA-ICP-MS U-Pb年代学及其地质意义[J].中国地质,2013,40(5):1600-1611.

    Google Scholar

    Shan L,Xu R K,Zheng Y Y,et al.Zircon LA-ICP-MS U-Pb Chronology of Magmatic Rock in the Baishantang Copper Polymetallic Deposit of Beishan Area,Northwest China[J].Geology in China,2013,40(5):1600-1611.

    Google Scholar

    [13] 柯于球,张路远,柴辛娜,等.硫化物矿物LA-ICP-MS激光剥蚀元素信号响应[J].高等学校化学学报,2012,33(2):257-262.

    Google Scholar

    Ke Y Q,Zhang L Y,Chai X N,et al.Elemental Signal Response of Sullfise Minerals in LA-ICP-MS Microanalysis[J].Chemical Journal of Chinese Universites,2012,33(2):257-262.

    Google Scholar

    [14] 袁继海,詹秀春,胡明月,等.基于元素对研究激光剥蚀-电感耦合等离子体质谱分析硫化物矿物的基体效应[J]. 光谱学与光谱分析,2015,35(2):512-518.

    Google Scholar

    Yuan J H,Zhan X C,Hu M Y,et al.Characterization of Matrix Effects in Microanalysis of Sulfide Minerals by Laser Ablation-Inductively Coupled Plasma-Mass Spectrometry Based on an Element Pair Method[J]. Spectroscopy and Spectral Analysis,2015,35(2):512-518.

    Google Scholar

    [15] 王彦斌,唐索寒,王进辉,等.安徽铜陵新桥铜金矿床黄铁矿Rb/Sr同位素年龄数据——燕山晚期成矿作用的证据[J].地质论评,2004,50(5):538-541.

    Google Scholar

    Wang Y B,Tang S H,Wang J H,et al.Rb-Sr Dating the Pyrite of the Xinqiao Cu-S-Fe-Au Deposit,Tongling,Anhui Province[J].Geological Review,2004,50(5):538-541.

    Google Scholar

    [16] 梅建明.浙江遂昌治岭头金矿床黄铁矿的化学成分标型研究[J].现代地质,2000,14(1):51-55.

    Google Scholar

    Mei J M.Chemical Typomorphic Characteristic of Pyrites from Zhilingtou Gold Deposit,Suichang,Zhejiang[J].Geoscience,2000,14(1):51-55.

    Google Scholar

    [17] 周学武,李胜荣,鲁力,等.辽宁丹东五龙矿区石英脉型金矿床的黄铁矿标型特征研究[J].现代地质,2005,19(2):231-238.

    Google Scholar

    Zhou X W,Li S R,Lu L,et al.Study of Pyrite Typomorphic Characteristics of Wulong Quartz-Vein-type Gold Deposit in Dandong, Liaoning Province,China[J].Geoscience,2005,19(2):231-238.

    Google Scholar

    [18] 王亚芬.海相火山岩型铜矿床中黄铁矿Co/Ni比值特征及地质意义[J].地质与勘探,1981(8):52-58.

    Google Scholar

    Wang Y F.Pyrite Co/Ni Ratio Characteristics and Geological Significance in Marine Volcanic Type of Copper Deposit[J].Geology and Exploration,1981(8):52-58.

    Google Scholar

    [19] 魏明秀.黄铁矿晶胞参数计算及某些杂质含量分布特征[J].矿物学报,1986,6(3):245-251.

    Google Scholar

    Wei M X.Cell Parameter Equation of Pyrite and Its Genetic Implications[J].Acta Mineralogica Sinica,1986,6(3):245-251.

    Google Scholar

    [20] Clark C,Grguric B,Mumm A S.Genetic Implications of Pyrite Chemistry from the Palaroproterozoic Olary Domain and Overlying Neoproterozoic Adelaidean Sequences,Northeastern South Australia[J].Ore Geology Reviews,2004,25:237-257. doi: 10.1016/j.oregeorev.2004.04.003

    CrossRef Google Scholar

    [21] 王奎仁编著.地球与宇宙成因矿物学[M].合肥:安徽教育出版社,1989:100-108.

    Google Scholar

    Wang K R.Genetic Mineralogy of Earth and Universe[M].Hefei:Anhui Geological Press,1989:100-108.

    Google Scholar

    [22] 徐国风,邵洁涟.黄铁矿的标型特征及其实际意义[J].地质论评,1980,26(6):541-546.

    Google Scholar

    Xu G F,Shao J L.Typomorphic Characteristics of Pyrite and Its Significance[J].Geological Review,1980,26(6):541-546.

    Google Scholar

    [23] 陕亮,郑有业,许荣科,等.甘肃北山地区白山堂铜矿地质特征及成矿流体研究[J].华南地质与矿产,2012,28(2):149-159.

    Google Scholar

    Shan L,Zheng Y Y,Xu R K,et al.Geological Features and Ore-forming Fluid of Baishantang Copper Deposit in Beishan Area,Gansu Province[J].Geology and Mineral Resources of South China,2012,28(2):149-159.

    Google Scholar
