THE GEOMETRICAL CHARACTERISTICS AND FORMATION MECHANISM OF POLYGONAL FAULTS IN DEEP-WATER BASIN

WU Shi-guo; SUN Qi-liang; DONG Dong-dong

2008 Vol. 14, No. 3

Article Contents

Article navigation > Journal of Geomechanics > 2008 > 14(3): 231-240

Next Article Previous Article

WU Shi-guo, SUN Qi-liang, DONG Dong-dong. THE GEOMETRICAL CHARACTERISTICS AND FORMATION MECHANISM OF POLYGONAL FAULTS IN DEEP-WATER BASIN[J]. Journal of Geomechanics, 2008, 14(3): 231-240.

Citation:

WU Shi-guo, SUN Qi-liang, DONG Dong-dong. THE GEOMETRICAL CHARACTERISTICS AND FORMATION MECHANISM OF POLYGONAL FAULTS IN DEEP-WATER BASIN[J]. Journal of Geomechanics, 2008, 14(3): 231-240.

THE GEOMETRICAL CHARACTERISTICS AND FORMATION MECHANISM OF POLYGONAL FAULTS IN DEEP-WATER BASIN

1.
Key Laboratory of Marine Geology and Environment, Institute of Oceanology, Chinese Academy of Sciences, Qingdao 266071, China
2.
Graduate University of Chinese Academy of Sciences, Beijing 100049, China

Received Date: 24 January 2008

Publish Date: 25 September 2008

Abstract

Abstract

Polygonal fault system is a tensional fault system with small throws.Because of their polygonal shape on plan, they are named polygonal faults.They have been studied for more than ten years since they were defined in North Sea in 1994, and from then on, they have been recognized in more than fifty passive basins worldwide.Research on polygonal fault needs high-resolution 3D seismic data, so, until now no research on polygonal fault has been made in China.The mechanism of polygonal fault is the focus of preliminary studies.Many experts think that the volumetric contraction induced by syneresis during the early-stage compaction of fine sedimentation is the mechanism for the development of polygonal fault systems.Many polygonal faults formed in continental slope, so some scholars believe that gravitational spreading is the mechanism for the polygonal fault formation.Polygonal faults affect the attributes and distribution of deep-water hydrocarbon reservoir which provide pathway for fluid, so they are important for migration and accumulation of hydrocarbon and gas hydrate.
- polygonal fault /
- syneresis /
- gravitational spreading /
- channel sandstone /
- deep-water basin

FullText(HTML)

References

[1]	Cartwright J A.Episodic basin-wide hydrofracturing of overpressured Early Cenozoic mudrock sequences in the North Sea Basin[J].Marine and Petroleum Geology, 1994, 11(5):587~607. doi: 10.1016/0264-8172(94)90070-1 CrossRef Google Scholar
[2]	Rundberg Y. Tertiary sedimentary history and basin evolution of the Northern North Sea[M]. Dr Ing. thesis, Trondheim, Norway, 1989. Google Scholar
[3]	Henriet J P, Batist D, Verschuren M. Early fracturing of Palaeogene clays, southernmost North Sea: relevance to mechanisms ofprimary hydrocarbon migration[J]. In: Generation, Accumulation and Production of Europe s Hydrocarbons(Ed. A. M. Spencer), Spec. Pub. Eur. Assoc. Petrol Geol 1, Oxford: Oxford University Press, 1991. 217~227. Google Scholar
[4]	Higgs W G, McClay K R. Analogue sandbox modelling of Miocene extensional faulting in the Outer Moray Firth[J]. In: Tectonics and Sequence Stratigraphy(Eds G. D. Williams and A. Dob). Spec Publ Geol Soc London No. 71, 1993. Google Scholar
[5]	Hansen D M, Shimeldb J W, Williamsonb M A, Andersena H L.Development of a major polygonal fault system in UpperCretaceous chalk and Cenozoic mudrocks of the Sable Subbasin, Canadian Atlantic margin[J].Marine and Petroleum Geology, 2004, 21:1205~1219. doi: 10.1016/j.marpetgeo.2004.07.004 CrossRef Google Scholar
[6]	Cartwright J A, Lonergan L.Volumetric contraction during the compaction of mudrocks:a mechanism for the development ofregional-scale polygonal fault systems[J].Basin Research, 1996, 8:183~193. doi: 10.1046/j.1365-2117.1996.01536.x CrossRef Google Scholar
[7]	Lonergan L, Cartwright J, Joliy R.The geometry of polygonal fault systems in Tertiary mudrocks of the North Sea[J].Journal ofStructural Geology, 1998, 20(5):529~545. doi: 10.1016/S0191-8141(97)00113-2 CrossRef Google Scholar
[8]	Dewhurst D N, Cartwright J. Lonergan L. The development of polygonal fault systems by syneresis of colloidal sediments[J]. Marine and Petroleum Geology, 1999a, 16: 793~810. Google Scholar
[9]	Cartwright J A, Dewhurst D N.Layer-bound compaction faults in fine-grained sediments[J].Geological Society of AmericaBulletin, 1998, 110:1242~1257. doi: 10.1130/0016-7606(1998)110<1242:LBCFIF>2.3.CO;2 CrossRef Google Scholar
[10]	Goulty N J.Mechanics of layer-bound polygonal faulting in fine-grained sediments[J].J.Geol.Soc.London, 2003, 159:239~246. Google Scholar
[11]	Gay A, Lopez M, Berndt C, Séranne M.Geological controls on focused fluid flow associated with seafloor seeps in the LowerCongo Basin[J].Marine Geology, 2007, 244:68~92. doi: 10.1016/j.margeo.2007.06.003 CrossRef Google Scholar
[12]	Shoulders S J, Cartwright J, Huusec M.Large-scale conical sandstone intrusions and polygonal fault systems in Tranche 6, Faroe-Shetland Basin[J].Marine and Petroleum Geology, 2007, 24:173~188. doi: 10.1016/j.marpetgeo.2006.12.001 CrossRef Google Scholar
[13]	Larter S, Aplina A C, Bowlera B, Lloyda R, Zwachb C, Hansenb S, Telnaesb N, Syltac O, Yardleyd G, Childse C.Adrain in my graben:an integrated study of the Heimdal area petroleum system[J].Journal of Geochemical Exploration, 2000, 69~70:619~622. Google Scholar
[14]	Victor P, Moretti I.Polygonal fault systems and channel boudinage:3D analysis of multidirectional extension in analogue sandboxexperiments[J].Marine and Petroleum Geology, 2006, 23:777~789. doi: 10.1016/j.marpetgeo.2006.06.004 CrossRef Google Scholar
[15]	Stuevold L M, Faerseth R B, Arnesen L, Cartwright J, Mller N. Polygonal faults in the Ormen Lange Field, More Basin, offshore Mid Norway[J]. In: Subsurface Sediment Mobilization. Geol. Soc. Spec. Publ, 2003, 16: 263~281. Google Scholar
[16]	Stewart S A.Implications of passive salt diapir kinematics for reservoir segmentation by radial and concentric faults[J].Marineand Petroleum Geology, 2006, 23:843~853. doi: 10.1016/j.marpetgeo.2006.04.001 CrossRef Google Scholar
[17]	Hansen D M, Cartwrigh J.The three-dimensional geometry and growth of forced folds above saucer-shaped igneous sills[J].Journal of Structural Geology, 2006, 28:1520~1535. doi: 10.1016/j.jsg.2006.04.004 CrossRef Google Scholar
[18]	Dewhurst D N, Cartwright J A, Lonergan L.Three dimensional consolidation of fine-grained sediments[J].Canadian Journal ofGeotechniques, 1999b, 36:1~8. doi: 10.1139/t98-093 CrossRef Google Scholar
[19]	Paola N D, Collettini C, Trippetta F, Barchi M R, Minelli G.A mechanical model for complex fault patterns induced byevaporite dehydration and cyclic changes in fluid pressure[J].Journal of Structural Geology, 2007, 29:1573~1584. doi: 10.1016/j.jsg.2007.07.015 CrossRef Google Scholar
[20]	Davies R J, Cartwright J A.Kilometer-scale chemical reaction boundary patterns and deformation in sedimentary rocks[J].Earthand Planetary Science Letters, 2007, 262:125~137. doi: 10.1016/j.epsl.2007.07.042 CrossRef Google Scholar
[21]	Trincardi F, Cattaneo A, Correggiari A, Ridente D.Evidence of soft sediment deformation, fluid escape, sediment failure andregional weak layers within the late Quaternary mud deposits of the Adriatic Sea[J].Marine Geology, 2004, 213:91~119. doi: 10.1016/j.margeo.2004.10.003 CrossRef Google Scholar
[22]	Bünz S, Mienert J, Berndt C.Geological controls on the Storegga gas-hydrate system of the mid-Norwegian continental margin[J].Earth and Planetary Science Letters, 2003, 209:291~307. doi: 10.1016/S0012-821X(03)00097-9 CrossRef Google Scholar
[23]	Gay A, Lopez M, Cochonat P, Levache D, Sermondadaz G, Seranne M.Evidences of early to late fluid migration from anupper Miocene turbiditic channel revealed by 3D seismic coupled to geochemical sampling within seafloor pockmarks, Lower CongoBasin[J].Marine and Petroleum Geology, 2006a, 23:387~399. doi: 10.1016/j.marpetgeo.2006.02.004 CrossRef Google Scholar
[24]	Gay A, Lopez M, Cochonat P, Seranne M, Levache D, Sermondadaz G.Isolated seafloor pockmarks linked to BSRs, fluidchimneys, polygonal faults and stacked Oligocene-Miocene turbiditic palaeochannels in the Lower Congo Basin[J].MarineGeology, 2006b, 226:25~40. Google Scholar
[25]	Watterson J, Walsh J, NICOL A, Nell P A R, Bretan P G.Geometry and origin of a polygonal fault system[J].Journal of theGeological Society, 2000, 157:151~162. doi: 10.1144/jgs.157.1.151 CrossRef Google Scholar
[26]	Nicola D P, Cristiano C, Trippetta F, Massimiliano R, Barchi, Giorgio M.A mechanical model for complex fault patternsinduced by evaporite dehydration and cyclic changes in fluid pressure[J].Journal of Structural Geology, 2007, 29(10):1573~1584. doi: 10.1016/j.jsg.2007.07.015 CrossRef Google Scholar
[27]	Panien M, Moretti I, Calassou S.Analogical model of the deformation of sandy submarine channels in shaly pelagic sediments[J].Oil&Gas Science and Technology-Review of IFP, 2001, 56(4):319~325. Google Scholar
[28]	Hustoft S, Mienert J, Bünz S, NouzéH. High-resolution 3D-seismic data indicate focussed fluid migration pathways abovepolygonal fault systems of the mid-Norwegian margin[J]. Marine Geology, 245: 89~106. Google Scholar
[29]	Gay A, Lopez M, Cochonatz P, Sermondadaz G.Polygonal faults-furrows systemrelated to early stages of compaction-UpperMiocene to recent sediments of the Lower Congo Basin[J].Basin Research, 2004, 16:101~116. doi: 10.1111/bre.2004.16.issue-1 CrossRef Google Scholar
