THE LATE MESOZOIC EXTENSION-SLIPPING-CONTRACTION OF THE ERLANGPING GROUP IN THE NORTH QINLING TECTONIC BELT, CENTRAL CHINA

ZHANG Hong-yuan; WANG Zong-qi; LIU Jun-lai; YAN Quan-ren; WANG Tao; YAN Zhen

2009 Vol. 15, No. 1

Article Contents

Article navigation > Journal of Geomechanics > 2009 > 15(1): 56-68

Next Article Previous Article

ZHANG Hong-yuan, WANG Zong-qi, LIU Jun-lai, YAN Quan-ren, WANG Tao, YAN Zhen. THE LATE MESOZOIC EXTENSION-SLIPPING-CONTRACTION OF THE ERLANGPING GROUP IN THE NORTH QINLING TECTONIC BELT, CENTRAL CHINA[J]. Journal of Geomechanics, 2009, 15(1): 56-68.

Citation:

THE LATE MESOZOIC EXTENSION-SLIPPING-CONTRACTION OF THE ERLANGPING GROUP IN THE NORTH QINLING TECTONIC BELT, CENTRAL CHINA

1.
State Key Laboratory of Geological Processes and Mineral Resources, China University of Geosciences, Beijing 100083, China
2.
Institute of Mining Resources, Chinese Academy of Geological Sciences, Beijing 100037, China
3.
Institute of Geology, Chinese Academy of Geological Sciences, Beijing 100037, China

Received Date: 20 November 2008

Publish Date: 25 March 2009

Abstract

Abstract

The convergence belt between the Sino-Korea block and the Yangtze block was strongly deformed by intracontinental tectonomagmatic activity in the Late Mesozoic.In order to show details of the belt during the Late Mesozoic, we have carried out a series of analysis for the Erlangping Group on mesosmall structure, micro-texture, electron-probe and geochronology.The study has recognized a ductile right lateral slipping deformation for the Xiaozhai-Erlangping shear zone inside the Erlangping Group, and a superimposion of ductile right lateral slipping and late brittle-ductile thrusting for the Damiao-Wantan shear zone.⁴⁰Ar/³⁹Ar tectonic-thermal chronological analysis reveals a continuous uplifting-denudating course between ~ 121 Ma and ~ 100 Ma.During the Late Mesozoic, the Erlangping Group experienced the tectonic reworkings respectively under the extensional, slipping and contractional tectonic regimes. Firstly, under the regionally extensional condition, the Erlangping Group was split by the XiaozhaiErlangping and Damiao-Wantan shear zones into three slabs, namely the Baoshuping, Huoshenmiao, and Erjingou slabs.Then in Early Cretaceous a right lateral movement of the slabs happened under a slipping regime.The intrusion of the Erlangping rock body ended the Xiaozhai-Erlangping shear zone, and the Damiao-Wantan shear zone was stopped under a contractional tectonic regime, which made the Erlangping Group welded into a single block again.Our results also indicated that the tectonic evolution of the Erlangping Group of the North Qinling in the Late Mesozoic processed in an opposite way to that of the Dabieshan tectonic belt.
- Late Mesozoic /
- the Erlangping Group /
- tectonic slab /
- shear zone /
- ⁴⁰Ar/³⁹Ar geochronology /
- tectonic regime

FullText(HTML)

References

[1]	张二朋.秦巴及邻区地质-构造特征概述[M].北京:地质出版社, 1993.1~291. Google Scholar ZHANG Er-peng.Geologic-tectonic features of Qinling-Dabashan Mountains and adjacent regions[M].Beijing :Geological Publishing House, 1993.1~291. Google Scholar
[2]	刘国惠, 张寿广, 游振东, 等.秦岭造山带主要变质岩群及其变质演化[M].北京:地质出版社, 1993.1~190. Google Scholar LIU Guo-hui, ZHANG Shou-guang, YOU Zhen-dong, et al.Main metamorphic groups and their metamorphic evolution of Qinling Orogen[M].Beijing :Geological Publishing House, 1993.1~190. Google Scholar
[3]	张复新, 杜孝华, 王伟涛, 等.秦岭造山带及邻区中生代地质演化与成矿作用响应[J].地质科学, 2004, 39 (4):486~495. Google Scholar ZHANG Fu-xin, DU Xiao-hua, WANG Wei-tao, et al.Mineralization responded to Mesozoic geological evolution of the Qinling Orogen and its environs[J].Chinese Journal of Geology, 2004, 39 (4):486~495. Google Scholar
[4]	姜春发.中央造山带主要地质构造特征[J].地学研究, 1993, 27:107~108. Google Scholar JIANG Chun-fa.Major geological and structural characteristics of the Central Orogenic Belts, China[J].Geoscience Research, 1993, 27:107~108. Google Scholar
[5]	张国伟, 张本仁, 袁学诚, 等.秦岭造山带与大陆动力学[M].北京:科学出版社, 2001.1~855. Google Scholar ZHANG Guo-wei, ZHANG Ben-ren, YUAN Xue-cheng, et al.Qinling orogen and continental dyanmics[M].Beijing :Science Press, 2001, 1~855. Google Scholar
[6]	索书田, 钟增球, 周汉文, 等.中国中央造山带内两个超高压变质带关系[J].地质学报, 2004, 78 (2):156~165. Google Scholar SUO Shu-tian, ZHONG Zeng-qiu, ZHOU Han-wen, et al.On the relationship between the two UHP metamorphic belts in the Central Orogenic Belt, China[J].Acta Geologica Sinica, 2004, 78 (2):156~165. Google Scholar
[7]	杨文采.中央造山带东段岩石圈的构造格架[J].中国地质, 2005, 32 (2):299~309. Google Scholar YANG Wen-cai.Tectonic framework of the eastern segment of the central orogenic belt of China[J].Chinese Geology, 2005, 32 (2):299~309. Google Scholar
[8]	许志琴, 杨经绥, 李海兵, 等.中央造山带早古生代地体构架与高压超高压变质带的形成[J].地质学报, 2006, 80 (12):1793~1806. doi: 10.3321/j.issn:0001-5717.2006.12.002 CrossRef Google Scholar XU Zhi-qin, YANG Jing-sui, Li Hai-bing, et al.The Early Paleozoic terrene framework and the formation of the high-pressure (HP)and ultra-high pressure (UHP)metamorphic belts at the Central Orogenic Belt (COB)[J].Acta Geologica Sinica, 2006, 80 (12):1793~1806. doi: 10.3321/j.issn:0001-5717.2006.12.002 CrossRef Google Scholar
[9]	赵亚曾, 黄汲清.秦岭山及四川之地质研究[J].地质专报甲种第9号, 1931. Google Scholar ZHAO Ya-zeng, HUANG Ji-qing.Geological research of Qinling Mountain and Sichuan[J].Geological Survey in China (Series A, No.9), 1931. Google Scholar
[10]	肖思云, 张维吉, 宋子季, 等.北秦岭变质地层[M].西安:西安交通大学出版社, 1988.1~320. Google Scholar XIAO Si-yun, ZHANG Wei-ji, SONG Zi-ji, et al.Metamorphic stratigraphy in North Qinling[M].Xi'an:Xi'an Jiaotong University Press, 1988.1~320. Google Scholar
[11]	赵宗溥.试论陆内型造山作用———以秦岭-大别山造山带为例[J].地质科学, 1995, 30 (1):19~28. Google Scholar ZHAO Zong-pu.An introcontinental-type orogeny :Evidence from Qinling-Dabie orogenic belt, China[J].Scientia Geologica Sinica, 1995, 30 (1):19~28. Google Scholar
[12]	刘军. 东秦岭二郎坪群变质作用[D]. 北京: 北京大学, 1987. Google Scholar LIU Jun. Erlangping metamorphism in the eastern Qinling[D]. Beijing : Peking University, 1987. Google Scholar
[13]	张阿利, 魏春景, 田伟, 等.北秦岭二郎坪群低压变质作用研究[J].岩石矿物学杂志, 2004, 23 (1):26~36. Google Scholar ZHANG A-li, WEI Chun-jing, TIAN Wei, et al.Low-pressure metamorphism of Erlangping Group in North Qinling Mountains [J].Acta Petrologica Et Mineralogica, 2004, 23 (1):26~36. Google Scholar
[14]	胡能高, 赵东林, 徐柏青, 等.北秦岭含柯石英榴辉岩的发现及其意义[J].科学通报, 1994, 21:2013. Google Scholar HU Neng-gao, ZHAO Dong-lin, XU Bai-qing, et al.The discovery of Coesite-bearing eclogite and its significance in North Qinling [J].Chinese Science Bullitin, 1994, 21:2013. Google Scholar
[15]	游振东, 韩郁菁, 杨巍然, 等.东秦岭大别高压超高压变质带[M].武汉:中国地质大学出版社, 1998.1~157. Google Scholar YOU Zhen-dong, HAN Yu-jing, YANG Wei-ran, et al.High pressure and ultra-high pressure metamorphic belt in East Qinling [M].Wuhan:Press of China University of Geosciences, 1998.1~157. Google Scholar
[16]	杨经绥, 许志琴, 裴先治, 等.秦岭发现金刚石:横贯中国中部巨型超高压变质带新证据及古生代和中生代两期深俯冲作用的识别[J].地质学报, 2002, 76 (4):484~495. Google Scholar YANG Jing-sui, XU Zhi-qin, PEI Xian-zhi, et al.Discovery of diamond in North Qinling :Evidence for a giant UHPM belt across central China and recognition of Paleozoic and Mesozoic dual deep subduction between North China and Yangtze Plates[J].Acta Geologica Sinica, 2002, 76 (4):484~495. Google Scholar
[17]	贾承造, 施央申, 郭令智.东秦岭板块构造[M].南京:南京大学出版社, 1988.1~130. Google Scholar JIA Cheng-zao, SHI Yang-shen, GUO Ling-zhi.Plate tectonics in the east of Qinling Mountain[M].Nanjing :Press of Nanjing University, 1988.1~130. Google Scholar
[18]	孙勇, 卢欣样, 韩松, 等.北秦岭早古生代二郎坪蛇绿岩片的组成和地球化学[J].中国科学(D辑), 1996, 26 (增刊):49~55. Google Scholar SUN Yong, LU Xin-xiang, HAN Song, et al.Composition and geochemistry of Erlangping ophiolite in North Qinling in Early Paleozoic era[J].Science in China (series D), 1996, 26 (Supp.):49~55. Google Scholar
[19]	张宗清, 张国伟, 刘敦一, 等.秦岭造山带蛇绿岩、花岗岩和碎屑沉积岩同位素年代学和地球化学[M].北京:地质出版社, 2006.1~348. Google Scholar ZHANG Zong-qing, ZHANG Guo-wei, LIU Dun-yi, et al.Isotopic chronology and geochemistry of ophiolites, granites and clastic sedimentary rocks in the Qinling orogenic belt[M].Beijing :Geological Publishing House, 2006.1~348. Google Scholar
[20]	张旗, 周国庆.中国蛇绿岩[M].北京:科学出版社, 2001. Google Scholar ZHANG Qi, ZHOU Guo-qing.Ophiolites in China[M].Beijing :Science Press, 2001. Google Scholar
[21]	王铭生, 武新强, 宋峰, 等.河南毛集-二郎坪断陷带主体构造格架的确立及意义[J].中国区域地质, 1999, 18 (1):23~27. Google Scholar WANG Ming-sheng, WU Xin-qiang, SONG Feng, et al.The establishment of the main structural framework of the MaojiErlangping down faulted zone in Henan and its significance[J].Regional Geology of China, 1999, 18 (1):23~27. Google Scholar
[22]	Ratschbacher L, Hacker B R, Calvert A, et al.Tectonics of the Qinling (CentralChina):Tectonostratigraphy, geochronology, and deformation history[J].Tectonophysics, 2003, 366:1~53. doi: 10.1016/S0040-1951(03)00053-2 CrossRef Google Scholar
[23]	张国伟, 孟庆任, 赖绍聪.秦岭造山带结构构造[J].中国科学(B辑), 1995, 25 (9):994~1003. Google Scholar ZHANG Guo-wei, MENG Qing-ren, LAI Shao-cong.Texture and structure of Qinling Orogen[J].Science in China (Series B), 1995, 25 (9):994~1003. Google Scholar
[24]	卢欣祥.秦岭花岗岩大地构造图(1:1000000)[M].西安:西安地图出版社, 2000. Google Scholar LU Xin-xiang.Tectonic map of granites in Qinling (1:1000000)[M].Xi'an:Xi'an Map Press, 2000. Google Scholar
[25]	席文祥, 巴光进, 亢进法.豫西卢氏县朱阳关组的建立[J].中国区域地质, 1994, 4:298~300. Google Scholar XI Wen-xiang, BA Guang-jin, KANG Jin-fa.The establishment of the Zhuyangguan Formation[J].Regional Geology of China, 1994, 4:298~300. Google Scholar
[26]	周世全, 朱广彬, 冯祖杰.河南内乡夏馆-高丘盆地的夏馆组及其时代[J].资源调查与环境, 2003, 24 (1): 69~74. Google Scholar ZHOU Shi-quan, ZHU Guang-bin, FENG Zu-jie.Xiaguan Formation and its era of Xiaguan-Gaoqiu Basin in Neixiang County, Henan Province[J].Volcanology & M ineral Resources, 2003, 24 (1):69~74. Google Scholar
[27]	田伟, 魏春景.北秦岭造山带加里东期低A1-TTD系列:岩石特征、成因模拟及地质意义[J].中国科学(D辑), 2005, 35 (3):215~224. Google Scholar TIAN Wei, WEI Chun-jing.Petrological features, formation model and geological significance of Caledonian low Al-TTD series in north Qinling orogen[J].Science in China (Series D), 2005, 35 (3):215~224. Google Scholar
[28]	高联达, 王宗起, 王涛, 等.河南西峡地区二郎坪群火神庙组中发现泥盆纪孢子化石[J].地质通报, 2006, 25 (11):1287~1294. doi: 10.3969/j.issn.1671-2552.2006.11.006 CrossRef Google Scholar GAO Lian-da, WANG Zong-qi, WANG Tao.Discovery of Devonian spores in the Huoshenmiao Formation of the Erlangping Group in the Xixia area, Henan, China[J].Geological Bullitin of China, 2006, 25 (11):1287~1294. doi: 10.3969/j.issn.1671-2552.2006.11.006 CrossRef Google Scholar
[29]	周汉文, 陈能松.豫西东秦岭造山带低压变质带的变质变形和变质反应[J].地球科学-中国地质大学学报, 1994, 19 (1):9~18. Google Scholar ZHOU Han-wen, CHEN Neng-song.Metamorphism, deformation and metamorphic reactions of low-pressure metamorphic belt in East Qinling Orogenic Belt, western Henan[J].Earth Science-Journal of China University of Geosciences, 1994, 19 (1):9~18. Google Scholar
[30]	Massonne H, Szpurka Z.Thermodynamic properties of white micas on the basis of high-pressure experiments in the systems K₂OMgO-Al₂O₃-SiO₂-H₂O and K₂O-FeO-Al₂O₃-SiO₂-H₂O[J].Lithos, 1997, 41:229~250. doi: 10.1016/S0024-4937(97)82014-2 CrossRef Google Scholar
[31]	赵东林, 胡能高, 安三元.北秦岭二郎坪岩群⁴⁰Ar/³⁹Ar坪年龄特征及其地质意义[J].矿物学报, 1998, 18 (1): 101~104. Google Scholar ZHAO Dong-lin, HU Neng-gao, AN San-yuan.⁴⁰Ar/³⁹Ar plateau age spectra of Erlangping Group, North Qinling and their geological implications[J].Acta M ineralogica Sinica, 1998, 18 (1):101~104. Google Scholar
[32]	Dodson M H.Closure temperature in cooling geochronological and petrological systems[J].Contributions to Mineralogy and Petrology, 1973, 40 (3):259~274. doi: 10.1007/BF00373790 CrossRef Google Scholar
[33]	Mark Harrison T.Diffusion of ⁴⁰Ar in hornblende[J].Contributions to Mineralogy and Petrology, 1981, 78 (3):324~331. Google Scholar
[34]	McDougall I, Harrison T M.Geochronology and thermochronology by the ⁴⁰Ar/³⁹Ar method[M].Oxford:Oxford University Press, 1999.1~269. Google Scholar
[35]	胡圣标, 郝杰, 付明希, 等.秦岭-大别-苏鲁造山带白垩纪以来的抬升冷却史-低温年代学数据约束[J].岩石学报, 2005, 21 (4):1167~1173. Google Scholar HU Sheng-biao, HAO Jie, FU Ming-xi, et al.Cenozoic denudation and cooling history of Qinling-Dabie-Sulu orogens:Apatite fission track thermochronology constraints[J].Acta Petrologica Sinica, 2005, 21 (4):1167~1173. Google Scholar
[36]	Zhang G W, Yu Z P, Sun Y, et al.The major suture zone of the Qinling orogenic belt[J].Southeast Asia Earth S cience, 1989, 3:63~76. doi: 10.1016/0743-9547(89)90010-X CrossRef Google Scholar
[37]	Xue F, Lerch F, Kröner A.et al.Tectonic evolution of the East Qinling Mountains, China, in the Paleozoic:A review and a new tectonic model[J].Tectonophysics, 1996, 253:271~284. doi: 10.1016/0040-1951(95)00060-7 CrossRef Google Scholar
[38]	王作勋, 王宗起, 姜春发, 等.秦岭造山带显生宙构造迁移与陶湾群沉积变形[M].北京:地震出版社, 1995. 1~104. Google Scholar WANG Zuo-xun, WANG Zong-qi, JIANG Chun-fa, et al.Phanerozoic structural dislocation and Taowan Group deformation in Qinling Orogen[M].Beijing:Seismic Publishing House, 1995.1~104. Google Scholar
[39]	姜春发.中央造山带几个重要地质问题及其研究进展(代序)[J].地质通报, 2002, 21 (8~9):453~455. Google Scholar JIANG Chun-fa.Several important geological problems and their research review in Central Orogenic Belt[J].RegionalGeology of China, 2002, 21 (8~9):453~455. Google Scholar
