Optimization of Cation Exchange Capacity Determination in Soil by Hexamminecobalt Trichloride Method

ZHANG Lei; WANG Lei; JIA Zhengxun; FAN Xingtao; GUO Lin

doi:10.15898/j.ykcs.202304240054

2024 Vol. 43, No. 3

Article Contents

Article navigation > Rock and Mineral Analysis > 2024 > 43(3): 509-516

Next Article Previous Article

ZHANG Lei, WANG Lei, JIA Zhengxun, FAN Xingtao, GUO Lin. Optimization of Cation Exchange Capacity Determination in Soil by Hexamminecobalt Trichloride Method[J]. Rock and Mineral Analysis, 2024, 43(3): 509-516. doi: 10.15898/j.ykcs.202304240054

Citation:

ZHANG Lei, WANG Lei, JIA Zhengxun, FAN Xingtao, GUO Lin. Optimization of Cation Exchange Capacity Determination in Soil by Hexamminecobalt Trichloride Method[J]. Rock and Mineral Analysis, 2024, 43(3): 509-516. doi: 10.15898/j.ykcs.202304240054

Optimization of Cation Exchange Capacity Determination in Soil by Hexamminecobalt Trichloride Method

1.
National Research Center for Geoanalysis, Beijing 100037, China
2.
Hubei Geological Research Laboratory, Wuhan 430034, China

More Information

Corresponding author: GUO Lin, guolno_1@aliyun.com

Received Date: 24 April 2023

Revised Date: 03 January 2024

Accepted Date: 09 March 2024

Publish Date: 31 May 2024

Abstract

Abstract

Compared with the traditional ammonium acetate exchange method and calcium acetate exchange method to determine cation exchange capacity (CEC), hexamminecobalt trichloride method has obvious advantages in the analysis of large quantities of samples. However, the application scope of this method is limited, and the detection results of neutral and alkaline samples are good, but the detection results of acidic samples are as low as 50%. In order to solve these problems, the pH was adjusted to alkaline with 2mol/L sodium hydroxide solution, the CEC value of the sample was significantly improved, and the determination results of both acidic and alkaline samples reached the range of standard values. By drawing the pH adjustment curve, the volume of 2mol/L sodium hydroxide solution was obtained in soil samples with different pH ranges, so as to adjust the pH value of unknown samples and realize the accurate determination of CEC. On the basis of the original method, the pH of the sample was adjusted to alkalinity, and the precision of the optimized method ranged from 1.02% to 3.82% (n=6). After optimization, the application scope of the method is expanded, the precision and accuracy are improved, and the detection efficiency of a large number of samples is effectively improved.
- cation-exchange capacity /
- extraction of hexamminecobalt trichloride /
- spectrophotometry /
- NaOH solution /
- pH value
